Quick start + safety guide

Shining GuardUser Guide

Thank you for buying Shining Slabs! Set up your display in minutes. Keep this guide for charging and safety information.

10Lighting modes
5VUSB-C charging
PSA · BGS · CGC · TAGSlab compatible
Interactive 3DDrag to rotate
The 3D view needs WebGL, which this browser has turned off. The diagrams below show the same parts.
01 · BacklitLEDs under the diffuser light your slab evenly from behind.
01 Backlit02 Slab03 Close
Preview colorsCrimson Red

01In the box

Shining Guard display, line drawing

Shining Guard display

Wireless · rechargeable
USB-C charging cable, line drawing

USB-C charging cable

Included

02Quick start

Set up your display in minutes.

01

Charge

Connect the included cable to a standard 5V USB charging source.

02

Power on

Press the LED On/Off button to activate the display.

03

Customize

Use Mode, Brightness, and Color to select your preferred look.

03Controls + status

Side view of the Shining Guard showing four buttons, the USB-C port and the charge indicator 1 2 3 4 5 6
  1. 1On/Off
  2. 2Mode Select
  3. 3Color Select
  4. 4Brightness
  5. 5USB-C charging port
  6. 6Charge indicator
Exploded view: top half, graded card slab, bottom half 7
  1. 7Magnetic dock portDock coming soon

Charge indicator

  • RedLow battery
  • YellowCharging
  • GreenCharged

04Lighting modes

Press Mode to cycle through the available effects.

01Rainbow
02Static
03Energy
04Star
058bit
06Haze
07Slab
08Tetris
09Gradient
10Split
Read before use

Safety + product disclaimer

STOP USE IMMEDIATELY if the battery becomes swollen, damaged, or excessively hot.

01Safe operation

Operation guidelines

  • Use the Shining Guard display only as intended.
  • Keep the display away from excessive heat, open flames, and direct sunlight.
  • Do not leave it inside a vehicle, near windows, or in other high-temperature environments.
  • Store the product in a cool, dry location when not in use.
  • Inspect the device periodically for damage or battery swelling.

Battery safety

This product contains a rechargeable lithium-polymer battery. Improper use, charging, storage, or handling may result in overheating, fire, or permanent device damage.

  • Do not puncture, crush, modify, or expose the battery to excessive heat.
  • Discontinue use immediately if the battery is swollen, damaged, or excessively hot.

Heat and airflow

The highest brightness setting is intended for temporary showcase use and may generate noticeable heat during extended operation. Enclosed spaces can increase heat buildup.

  • Avoid maximum brightness for extended periods.
  • Ensure adequate airflow around the display.
  • Reduce brightness if the enclosure or display becomes warm.
  • Use caution inside slab bags, carrying cases, or other confined spaces.

Charging requirements

Use only standard 5V USB charging sources and USB-C charging cables compatible with 5V operation.

  • Do not use USB-C Power Delivery (PD) laptop chargers.
  • Do not use charging devices that supply voltages above 5V.
  • Incompatible charging equipment may damage the product and void any applicable warranty.

02Impact + shock disclaimer

Shining Guards are not rated for shock or impact protection.

The display is designed to enhance the presentation of compatible graded trading cards. It securely holds compatible slabs during normal display and handling, but must not be relied upon to protect cards from drops, impacts, crushing forces, or other physical damage.

03Care at a glance

5V only

Use a standard 5V USB source.

Keep cool

Avoid heat, sunlight, and hot vehicles.

Allow airflow

Lower brightness if the display feels warm.

Inspect

Stop use if damaged, swollen, or very hot.
